Modular Office & Inplant Building Case Studies
Two-Story Modular Building
Application: Office Space, Conference Space, Locker Rooms & Quality Testing Lab
Location: Fort Payne, AL
Product: OmniFlex Vinyl Fire & Sound – 10’ lower 9’ upper (90’ x 26’ x 90)
Benefits:
- New office, conference, laboratory and locker room space
- Assistance with construction permits, specifications and approval drawings via our distributor
- Effective utilization of existing space via three-wall, two-story layout
Two-Story Mezzanine Office Building
Application: Offices, training and research space
Location: St Charles, MO
Product: OmniFlex Fire & Sound (gray)
Benefits:
- Allocated new space while minimizing lateral footprint by expanding vertically.
- Distributor coordinated installation of both office walls and mezzanine.
”Quick-Ship” Warehouse Office
Application:Shipping & Receiving Managers Office
Location: Michigan
Product: OmniFlex Fire & Sound (white)
Benefits:
- Quick order and delivery to meet demand
- Minimized cost by using modular electric
- Potential for future reconfiguration
Elevated Plant Supervisors Office
Location: Stevensville, MI
Product: OmniFlex Vinyl Fire and Sound
Benefits:
- Fast delivery and installation due to quick-ship program and modular electrical wiring.
- Elevated office on a mezzanine to provide clear view of entire manufacturing processes.
Quality Inspection Room
Location: South Carolina, US
Application: Glass Manufacturer Inspection Room
Product: OmniFlex 14’ Tall Steel Fire & Sound
Benefits Provided:
- Temperature-controlled enclosure with particle filtration to improve product quality and aid inspection process.
- Extra-high walls to accommodate large equipment inside, while installing the building neatly underneath existing bridge crane outside.
- Steel framing for structural integrity and Fire & Sound panels for thermal control.
Modular Office Complex
Location: Charlotte, NC
Application: Modular Offices
Product: OmniFlex System 9-Feet Tall
Benefits Provided:
- Integrated new office walls with existing walls matching in color and appearance.
- Noise reduction inside offices from nearby manufacturing processes with Fire and Sound panels.
- Modular advantages including expandability, ability to re-locate and versatility of structures for a dynamic and growing company.
Modular Break Room & Showroom
Location: Sturtevant, WI
Application: Multi-Purpose Inplant Building
Product: OmniFlex (18-foot tall)
Benefits:
- Extra-tall windows with open view of manufacturing floor.
- Reduced labor costs by utilizing 3-wall design & suspended ceiling system.
- 18-foot high walls and open interior floor plan to accommodate large demonstrations.
Modular Communications Closets
Customer: Automobile Manufacturer
Application: Telecommunications and Network Storage
Product: 10' x 10' Preassembled Buildings
Benefits Provided:
- Reduced time and labor by using prefabricated modular units.
- All-welded aluminum framework provided structural integrity for locating the buildings.
- Units outfitted with customized electrical requirements to meet application specifications.
Training Center with Glass Wall Partitions
Client: Volkswagen Academy in Chattanooga, TN
Products: OmniFlex (15 feet tall), Full Glass Windows and Fire & Sound Panels
Benefits Provided:
- Attractive appearance
- Flexibility to create different sized training rooms
- LEED points for the construction project
- Quick turnaround time
Parts Storage & Distribution Area
Application: 2,555 sq ft in-plant building with secured storage area.
Product: OmniFlex with Fire & Sound Panels
Benefits Provided:
- Flexibility to move in future
- Secure, enclosed area with sound control
- Minimal disruption to plant during construction
Two Story In-Plant Office Building
Application: New two story modular office within existing manufacturing plant facility
Product: OmniFlex
Benefits Provided:
- Expanded usable office space without enlarging existing footprint
- Engineering and operations teams given direct access to plant operations
- Effectively used vertical square footage
Warehouse Offices & Storage Space
Application: 2,778 sq. ft. office complex, consisting of two story and single story offices with storage decks.
Product: Series 300
Benefits Provided:
- Tied into existing modular offices
- Attractive appearance
- Maximized floor space
Prefab Office Space
Application: 2,430 square foot 2-story office
Product: Series 300
Benefits Provided:
- Adapt design to needs without seriously impacting budget or time line
- Professional appearance
- Sound control
Sound-Resistant Modular Office
Application: Two-Story Office with Sound-Resistant Properties
Product: OmniFlex
Benefits Provided:
- Effective sound control
- Ability to re-locate easily
- Minimal disruption to existing business
Load-Bearing Modular Building
Application: Modular Offices and Lunchroom with Storage Decks
Product: Series 300 with Fire & Sound Wall Panels
Benefits Provided:
- Effective sound control
- Ability to re-locate easily
- 2-Story design to maximize space utilization
Equipment / Machine Enclosure
Location: Elk Grove Village, IL
Application: Thermal Enclosure to Protect High-Tech Equipment
Product: OmniFlex Insulated Panels
Benefits Provided:
- Cleaner alternative to modern construction
- Insulated walls for optimal thermal control
- Flexibility of reconfiguration in the future
Control Pulpit for Steel Mill
Location: Warsaw, KY
Client: North American Stainless
Product: OmniFlex Steel Fire & Sound
Benefits Provided:
- Tall windows provide 180 degree unobstructed view
- Heightened platform allows max visibility of facility
- Climate-controlled, sound-proof room protects operator from extreme steel mill environment
Laboratory and Office Space
Location: Chicago, IL
Client: Vegetable Juices, Inc.
Product: OmniFlex Fire & Sound
Benefits Provided:
- Two-story building to house lab and office space
- Odors contained within lab on ground floor
- Contemporary design and appearance
Modular Electric Wiring
Application: Office and Conference Room
Product: Modular Electric Wiring System
Benefits Provided:
- Rapid installation
- Reduced project cost
- Flexibility of reconfiguration in the future
2-Story Inplant Office Building
Location: Minneapolis, MN
Application: Warehouse Manager Offices
Product: OmniFlex Fire & Sound Panels
Benefits Provided:
- Minimized space by building vertically
- Reduced project cost
- Quick installation
Training Area and Conference Space
Client: Los Angeles Police Dept.
Application: 2-Story Modular Building
Product: OmniFlex Fire & Sound (Steel Exterior, Vinyl Interior)
Benefits Provided:
- Space for training purposes and meetings
- Security and adherence to local building codes
- Saved lateral space by building vertically
Secured Storage Enclosure
Location: Minneapolis, MN
Application: 3-Wall Modular Building
Product: OmniFlex Steel Fire & Sound Panels
Benefits Provided:
- Minimized space by building vertically.
- Reduced project cost with 3-wall design.
- Emphasized "green" building standards.
Industrial In-Plant Office Building
Location: Toronto, Canada
Client: A1 Label
Product: Series 300 Fire & Sound Panels (12-feet high)
Benefits Provided:
- Extra tall ceiling and wide doors to accomodate large equipment.
- Sound-resistant wall panels to minimize noise from surrounding printing machines.
- Open atmosphere as a result of large surrounding windows.
Equipment Supply Depot
Location: Bome, Equatorial Guinea
Client: Hess Corporation
Product: OmniFlex F&S
(Vinyl Exterior and FRP Interior) 35' 11 x 99'3"
Benefits Provided:
- Utilized PortaFab's installation network
- FRP Walls for durability and cleanability for the shower and locker room
- Incorporated plumbing chases within structure
- 125 PSF Loadbearing roof to utilize existing overhead space
Environmental Enclosures
Paint Finishing Enclosure
Location:Gwenner, ND
Application: 32’ X 88’ X 24’ Tall Paint Finishing Enclosure
Product Used: PortaMax 4-5/8 & OmniFlex Wall Systems
Benefits Provided:
- Effective environmental control
- Timely installation with minimal disruption to plant
- Met 24’ height requirements
Pharmaceutical Sampling Booth
Location: Greeneville, IL
Client: Mallinckrodt Pharmaceuticals
Product: Cleanline S3000 with FRP Wall Panels
Benefits:
- Met requirements for ISO 8 and ISO 7 level classifications
- Structure designed and built to comply with EU standards
- Integrated controls for high-speed conveyor system to create automated process
- Dedicated HVAC system to maintain temperature and humidity requirements
CMM Room, Lab and Office Space
Location: Western Canada
Distributor: Central Warehouse Equipment
Application: Coordinate Measuring Machine Enclosure, Lab Space & Offices
Product: OmniFlex Vinyl (white)
Benefits:
- Effective environmental control to protect processes within CMM room
- Additional office space by expanding vertically
- Improved throughput through addition of QA/QC lab
- Maximize vertical space, minimizing impact to valuable plant floor space
Coordinate Measuring Machine (CMM) Enclosure
Location: Houston, TX
Application: CMM Room Enclosure
Product: OmniFlex Steel with Fire & Sound Panels (Champagne)
Benefits Provided:
- Steel surfaces for ease of cleanability, durability and non-shedding surfaces to reduce particulates.
- Temperature and airflow controlled environment to provide reliable testing and measurement.
- Extra-tall walls and roll-up door to ease transfer of large equipment in and out of enclosure.
Food Process Enclosure
Customer: Worldwide Medical, Pharmaceutical and Nutrition Company
Application: Containment Area for Mixing & Bottling Baby Formula
Product: PortaMax Aluminum System Featuring Epoxy-coated Aluminum Panels (Fire and Sound) with Moisture-Resistant Gypsum (17’4” - 20’ tall because of the ceiling truss)
Benefits Provided:
- Epoxy-coated surfaces comprised of moisture-resistant gypsum to withstand water penetration during cleaning process.
- Floor to ceiling wall system seated upon 6-inch high curb (to contain excess water during wash down).
- Seamless integration of walls with existing conveyor system, concrete columns and trussed ceiling.
Modular Wall Cladding at Fish Hatchery
Location:: Huntsdale, PA
Application: Composite Panel Wall & Ceiling Cladding
Product: Furring 500 FRP over ½” thick Plywood
Benefits:
- Customized solution to meet the particular needs of our client.
- Seamless and durable wall and ceiling cladding to withstand cleaning and high moisture environment.
- Economical alternative to conventional construction.
Painting Process Enclosure
Location: Rome, GA
Client: Suzuki
Product: OmniFlex Steel-Faced Panels (16 feet tall)
Benefits Provided:
- Insulated walls for optimal thermal control
- Improved product yield
- Integration with existing conveyor system
Battery Storage Enclosure
Customer: A123 Systems
Location: Detroit, MI
Product: PortaMax 458 steel stud (23 feet tall)
Benefits Provided:
- Insulated walls for optimal thermal control
- Removable exterior walls
- Doors located for aisle access
CMM Room / Equipment Enclosure
Location: Columbus, Indiana
Client: Toyota
Product: S3000 with Fire & Sound Wall Panels
Benefits Provided:
- Humidity and temperature control
- Ability to relocate easily
- Sound insulation
Powder Coating System Enclosure
Location: Grand Rapids, MI
Client: American Seating
Product: OmniFlex (56' x 58' x 16' Tall)
Benefits Provided:
- Effective environmental control
- Effective sound control
- World class appearance
Equipment Enclosure / Modular Construction
Location: Fairfield, Illinois
Application:Equipment Enclosure Room, Conference Room, Plant Separation
Product: XTRA TALL Wall Systems, Series 300
Benefits Provided:
- Consistent appearance throughout plant
- Effective environmental control
- Flexibility to relocate
Laser Equipment Enclosures
Location: Minneapolis, MN
Client: Innovative Laser Technologies, Inc.
Product: OmniFlex Fire & Sound
Benefits Provided:
- Walls made of fire retardant materials
- Open design, utilizing pre-existing lighting & sprinkler system
- Laser safety glass windows in doors
Demising Walls for Warehouse Segregation
Location: Marion, Kentucky
Client: Siemens
Product: XTRA TALL Wall System (270' Long x 21'-24' tall)
Benefits Provided:
- Protect sensitive machinery
- Improve appearance of plant to visitors
- Increase space utilization
Environmental Control
Location: Grand Rapids, MI
Application: 30' high x 630' long wall in manufacturing plant
Product: PortaMax XTRA TALL Wall System
Benefits Provided:
- Effective environmental control
- Clean installation process allowed for continuous operation
- Flexibility to re-locate and re-use in future
Medical Equipment Storage
Location: Joliet, IL
Application: Climate-Controlled Area to House Medical Equipment
Product: SteelSpan Wall System (350 lineal feet, 28 ft tall)
Benefits Provided:
- Proper R-value of insulation to house equipment
- Fast installation
- Area accessible by fork lift via high-speed roll up doors
- Flexibility of modular wall system
Thermal Equipment Enclosures
Location: Midwest US
Application: Thermal Equipment Enclosures
Product: SteelSpan 28-Foot Tall
Benefits Provided:
- 28-foot tall thermal enclosures for equipment and manufacturing processes
- Ability to reconfigure the space based on client needs
- Office space allowing facility engineers to be in closer proximity to manufacturing
- Accelerated depreciation
Coordinate Measuring Equipment Enclosure
Location: Cleveland, NC
Client: Hersey Meters
Product: PortaMax 458s 20' Tall Thermal Steel Wall Panels
Benefits Provided:
- Thermal control to protect equipment & processes
- Panel construction featuring an R-value of 20
- Full-height windows for viewing of processes & equipment
- Ability to offer factory tours without disruption of processes
CMM Equipment Enclosure
Customer: Mining Equipment Manufacturer
Application: Thermal-controlled CMM equipment enclosure
Product: OmniFlex Fire and Sound (16-foot tall)
Benefits Provided:
- Building constructed to withstand tight tolerances for measuring
- Roll up doors to allow safe passage of large equipment while maintaining environmental control
- Integrated wall system with bridge crane for use in transferring large equipment
Wall Partitions & Demising Walls
Full Glass Wall Partitions
Client: Fitzgerald Trucking
Product: OmniFlex Vinyl Fire and Sound (8-1/2’ tall)
Benefits Provided:
- Reduced debris and installation timeframe by ordering pre-cut panels
- Flexibilaity to reconfigure if needs change
- Installation completed during normal business hours
Freestanding Industrial Wall Partitions
Client: AeroVironment, Inc.
Product: OmniFlex with Freestanding Wall Panels
Benefits Provided:
- Segregated Work Areas
- Provided Visibility Into Work Areas
- Lower Cost than Standard Furniture Alternative
- Custom Painted to Match Existing Structures
Medical Equipment Packaging Enclosure
Client: Crown Cork & Steel
Product: SteelSpan (28' tall)
Benefits Provided:
- Divided packaging area from the rest of the facility.
- Contained noise and particles.
- Operator could oversee production from outside of packaging area.
Separation Wall & Bulletin Board
Client: Hyundai North America
Product: OmniFlex
Benefits Provided:
- Separated space
- Provided meeting area
- Provided posting vehicle
Free-Standing Wall Partitions
Client: Novartis Pharmaceuticals Corp.
Application: Separation of Manufacturing Space
Product: OmniFlex (76 Linear Feet & 80" tall)
Benefits Provided:
- Separated manufacturing space
- Aided in achieving FDA compliance
- Blended well with existing partitions
Demising Walls for Plant Separation
Location: Plainfield, NJ
Client: PIM Brands, LLC
Product: SteelSpan Wall System (30 foot tall)
Benefits Provided:
- Separation of manufacturing and distribution areas
- Fast installation
- Compliance with local building codes
Mezzanine Case Studies
Modular Offices on a Mezzanine
Location: Ames, IA
Application: Modular Offices on a Mezzanine
Product: 3” OmniFlex wall system with Modular Wiring Package
Benefits Provided:
- 3 new offices, each complete with electrical, HVAC, windows and exterior doors
- Minimized lateral footprint by expanding vertically within production facility
- Mezzanine design which allowed existing processes to continue underneath
- Flexibility for future reconfiguration by utilizing modular systems
Mezzanine Storage Solution
Location: Colorado Springs, CO
Application: Mezzanine Storage and Laboratory Space
Product: OmniFlex Fire and Sound - Gray
Benefits Provided:
- Expanded vertically by incorporating a mezzanine design.
- Storage solution adhered to local fire code and did not require expansion of existing facility.
- Ability to reconfigure layout and adapt to future business changes or expansion.
- Turnkey solution featuring fire suppression, HVAC, lighting and engineering & building permits.
Elevated Warehouse Control Rooms
Client: Waste Management, Inc.
Location: New York
Application: 67" x 10" and 67" x 30' control rooms elevated on 25' high mezzanine
Product: OmniFlex
Benefits Provided:
- Safe, comfortable work area
- Installation with minimal disruption
Modular Office on Mezzanine
Client: Master Lock
Product: OmniFlex (40' x 100')
Benefits Provided:
- Added space within plant and better view for foreman to monitor activity
- Provided sound reduction to improve worker productivity
- Met complex building code requirements within budget
Offices on Mezzanine
Location: Beaverton, OR
Client: NIke
Product: OmniFlex Fire & Sound (14 foot tall)
Benefits Provided:
- Integrated structure with existing mezzanine to minimize space
- Saved cost by utilizing existing lighting, ceiling & fire protection
- Flexible design based on local building codes
- Ease of future reconfiguration if needed
Military Training Complex
Location: Virginia, US
Application: Military Training Complex
Product: OmniFlex Steel Fire and Sound
Benefits Provided:
- Support from Distributors to Coordinate Multiple product Lines
- Variety of indoor enclosures for multiple training scenarios
- Deployable and Flexibility to modify training area for enhanced training value
- Integration of non-standard equipment within structure
Air National Guard Facility
Location: Southern, United States
Application: Offices, Conference Room and Classroom on a Mezzanine
Product: OmniFlex Fire and Sound
Benefits Provided:
- 2-story mezzanine with offices and training areas
- Financial savings with modular construction
- Ease of procurement
- Integration of modular systems with mezzanine manufacturer
Print Process Enclosure Built on Mezzanine
Customer: Print and Packaging Manufacturer
Location: Southern CA
Application: Printing process enclosure and office space integrated into mezzanine
Product: OmniFlex (Gray) Fire and Sound
Benefits Provided:
- Temperature and humidity controlled & dust-free enclosure
- Increased storage space utilizing mezzanine
- Integrated new buildings with existing buildings by matching height and enclosed catwalk
- Incorporated laminated glass windows to reduce noise of surrounding environment
Cleanroom Case Studies
Cleanroom for Medical Device Manufacturing
Product: Series 300 Vinyl Fire and Sound / Furring 500
Application: ISO 8 / Class 100,000 Vestibule and Cleanroom
Benefits:
- Minimal impact to facility during installation.
- Environmental control for ISO 8 validation.
- Coordination with construction trades for efficient construction process.
E-Liquid Manufacturing Clean Room
Location: Grand Rapids, MI
Application: E-Liquid Manufacturing Cleanroom
Product Line: OmniFlex Two-Story Building
Benefits:
- Provided a clean environment that met ISO 6 (Class 1,000) classification
- Fast and low mess installation allowed client to maintain manufacturing progress, uninterrupted during the new construction project.
- Flexibility to expand or even re-locate the building due to future growth or changes in business needs.
Cleanroom for O-Ring Manufacturing
Location: Lexington, KY
Application: Cleanroom ISO 7 (Class 10,000)
Product: Series 300 with FRP Fire & Sound Panels
Benefits:
- A complete, turn-key solution through PortaFab’s existing network of cleanroom contractors.
- Multiple clean environments in which to contain each stage of the manufacturing process.
- ISO 7 (Class 10,000) classification.
- Recirculating airflow design and positive pressure.
Semiconductor Cleanroom
Location: Colorado Springs, CO
Application: Cleanroom
Product: Series 300 & P2000 ESD (electro-static discharge) Epoxy-Coated Aluminum Skins on Fire & Sound Panels.
Benefits Provided:
- Anti-static wall system to maintain standards for semiconductor fabrication.
- Double-wall system to ensure maximum envirionmental control.
- Removable wall section to ease transfer of large equipment.
- Use of P2000 wall system for economical construction of gowning area and air shower entry.
Cleanroom for Polymers Research
Location: Cleveland, OH
Application: Cleanroom (ISO 7 & ISO 8)
Product: Series 300 with Vinyl Fire & Sound Panels
Benefits Provided:
- Multiple ISO classifications for different areas including gowning room, storage area and main lab.
- High visibility windows to serve as client demonstration area.
- Complete turn-key solution through PortaFab’s involvement with general contractor, pre-construction meetings and on-site supervision during installation.
Underground Cleanroom
Location: Lead, South Dakota
Application: Controlled Environment
Product: OmniFlex 11' Tall with Steel/Poly/Steel Panels
Benefits Provided:
- Thermal control to protect expensive research equipment
- Dust and particulate-free environment to minimize the possibility of contamination
Class 100 (ISO 5) Cleanroom
Location: Opelika, Alabama
Client: Ampex Recording Media
Product: CleanLine S3000 (30,000 S.F.)
Benefits Provided:
- Flexibility
- Class 100 / ISO 5 conformance capability
Class 1,000 (ISO 6) Cleanroom
Location: Englewood, Colorado
Client: Pozzetta Micro Clean
Product: CleanLine S3000 with Flush Windows (1,000 sq ft)
Benefits Provided:
- Speed of completion
- Corporate showpiece for attracting new business
Class 100,000 (ISO 8) Industrial Cleanroom
Location: Lafayette, Indiana
Client: Caterpillar
Product: OmniFlex
Benefits Provided:
- Allowed operation to comply with quality guidelines from major customer.
- Integrated with conveyors and bridge crane with minimal plant disruption.
Cleanroom for Electronics Manufacturing
Location: Springboro, Ohio
Client: Pioneer Electronics
Product: OmniFlex (2,000 ft)
Benefits Provided:
- Improved quality
- Increased product yield
Cleanroom for Food Packaging Process
Location: Compton, California
Application: Achieving USDA Compliance in Mixing and Packaging
Product: PortaMax 458 XTRA TALL Wall System
Benefits Provided:
- Quality control
- USDA compliance
- Improved product yield
Cleanroom for Medical Device Manufacturing
Location: Winston-Salem, NC
Client: Wilson Cook Medical
Product: PM458 XTRA TALL Wall System (20,000 sq ft)
Benefits Provided:
- Capability to achieve cleanliness and air quality standards
- Flexibility to relocate
- Minimal disruption and speed of construction
Cleanroom for Medical Device Packaging
Location: Clearwater, MN
Client: T.O. Plastics
Product: Series 300 Panels with Anondized-Aluminum Framework FRP (Fiberglass Reinforced Plastic)
Benefits Provided:
- Cleanability
- Recirculating air flow to meet ISO standards
- Pass-through chamber to maintain cleanroom integrity
Cannabis Cultivation Room Case Studies
Two-Story Cleanroom with a High Bay for Cannabis Cultivation
Application: Cannabis Cultivation Facility
Location: Denver, CO
Product: Series 300 with aluminum framework and insulated panels
Benefits:
- Fast and clean installation that resulted in faster permit and license obtainment
- Load-bearing structural system that allowed for high bays with an integrated racking / growing system
